ENGINE
Type  Single Cylinder SOHC 4 Stroke Dual Valve, Air Cooled Petrol Engine
Displacement  124.84 CC
Bore x Stroke  57.03 x 48.89
Ignition Type  CDI
Starting Type  Kick and Electric
Max Power  11.256 bph @ 8500rpm
Max Torque  11.0 N.m @ 7000 rpm
Mileage  N/A
Compression Ratio  9.5:1
Cooling  Air Cooled

BODY
Clutch  Multiple wet
Chassis  Diamond
Gear Box  1 Forward, 4 reverse
Number of Cylinder  1

BRAKE
Front Brake  Hydraulic disc
Rear Brake  Drum

Wheeles & Tyre
Rim Size Front  1.6x18
Rim Size Rear  1.85x18
Tyre Size Front  2.75-18
Tyre Size Rear  90/90-18
Front  Hydraulic Telescopic
Rear  Nitrox Shock absorber

Electric
Battery  12V/7AH
Head Light  N/A
Tail Light  N/A
Signal Light  N/A
Horn  N/A

DIMENSION (mm)
Length(mm)  2020
Width(mm)  840
Height(mm)  1240
Wheel Base(mm)  1320
Ground Clearance(mm)  160
Dry weight(kg)  133 kg (approx)
Max. weight with Pay load (kg)  283 kg
Fuel Tank Capacity  15.0 L
