Memory Specifications

Max Memory Size (dependent on memory type) 128 GB

Memory Types DDR4-2666

Max # of Memory Channels 2

Max Memory Bandwidth 41.6 GB/s

ECC Memory Supported ‡ No

GPU Specifications

GPU Name‡ Intel® UHD Graphics 630

Graphics Base Frequency 350 MHz

Graphics Max Dynamic Frequency 1.10 GHz

Graphics Video Max Memory 64 GB

4K Support Yes, at 60Hz

Max Resolution (HDMI)‡ 4096x2304@24Hz

Max Resolution (DP)‡ 4096x2304@60Hz

Max Resolution (eDP - Integrated Flat Panel)‡ 4096x2304@60Hz

DirectX* Support 12

OpenGL* Support 4.5

Intel® Quick Sync Video Yes

Intel® InTru™ 3D Technology Yes

Intel® Clear Video HD Technology Yes

Intel® Clear Video Technology Yes

# of Displays Supported ‡3

Device ID0x3E92

Expansion Options

Scalability1S Only

PCI Express Revision 3.0

PCI Express Configurations ‡ Up to 1x16, 2x8, 1x8+2x4

Max # of PCI Express Lanes 16

Package Specifications

Sockets Supported FCLGA1151

Max CPU Configuration1

Thermal Solution Specification PCG 2015C (65W)

TJUNCTION 100°C

Package Size37.5mm x 37.5mm

Advanced Technologies

Intel® Optane™ Memory Supported ‡ Yes

Intel® Turbo Boost Technology ‡ 2.0

Intel® Hyper-Threading Technology ‡ No

Intel® Transactional Synchronization Extensions Yes

Intel® 64 ‡ Yes

Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States Yes

Enhanced Intel SpeedStep® Technology Yes

Thermal Monitoring Technologies Yes

Intel® Identity Protection Technology ‡ Yes

Security & Reliability

Intel vPro® Eligibility ‡ Intel vPro® Platform

Intel® AES New Instructions Yes

Secure Key Yes

Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME

Intel® Memory Protection Extensions (Intel® MPX) Yes

Intel® OS GuardYes

Intel® Trusted Execution Technology ‡ Yes

Execute Disable Bit ‡ Yes

Intel® Boot Guard Yes

Intel® Stable IT Platform Program (SIPP) Yes

Intel® Virtualization Technology (VT-x) ‡ Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes

Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
