Technical Specification

ENGINE
Type Four stroke Petrol engine
Displacement 86 CC
Bore x Stroke 47 x 49.5
Ignition Type CDI
Starting Type kick/electrcic start
Max Power 4.4 kw @ 7500 rpm
Max Torque 5.5 N.m @ 4500 rpm
Mileage N/A
Compression Ratio 8.5 : 1
Cooling Air Cooled

BODY
Clutch Multiple wet
Chassis Fabricated Spine
Gear Box 4 Forward, no reverse
Number of Cylinder 1

BRAKE
Front Brake Drum
Rear Brake Drum

Wheeles & Tyre
Rim Size Front 1.2x17
Rim Size Rear 1.4x17
Tyre Size Front 2.50-17
Tyre Size Rear 2.75-17
Front Hydraulic Telescopic
Rear Coil spring Hydraulic

Electric
Battery 12V/5AH
Head Light N/A
Tail Light N/A
Signal Light N/A
Horn N/A

DIMENSION (mm)
Length(mm) 1840
Width(mm) 795
Height(mm) 1210
Wheel Base(mm) 1200
Ground Clearance(mm) 150
Dry weight(kg) 86 kg
Max. weight with Pay load (kg) 226 kg
Fuel Tank Capacity 9.0 L
