ENGINE
Type  Single Cylinder SOHC 4 Stroke Dual Valve, Air Cooled Petrol Engine
Displacement  85 CC
Bore x Stroke  47 x 49.5
Ignition Type  CDI
Starting Type  Kick and Electric
Max Power  6.1372 bhp @ 8000 rpm
Max Torque  5.7 nm @ 6000 rpm
Mileage  N/A
Compression Ratio  8.8 : 1
Cooling  Air Cooled

BODY
Clutch  Multiple wet
Chassis  Fabricated Spine
Gear Box  4 Forward, no reverse
Number of Cylinder  1

BRAKE
Front Brake  Drum
Rear Brake  Drum

Wheeles & Tyre
Rim Size Front  AD 80 Deluxe
Rim Size Rear  1.6x17
Tyre Size Front  2.50-17
Tyre Size Rear  2.75-17
Front  Hydraulic Telescopic
Rear  Coil spring Hydraulic

Electric
Battery  12V/5AH
Head Light  N/A
Tail Light  N/A
Signal Light  N/A
Horn  N/A

DIMENSION (mm)
Length(mm)  1880
Width(mm)  865
Height(mm)  1170
Wheel Base(mm)  1235
Ground Clearance(mm)  179
Dry weight(kg)  86.7 kg (approx)
Max. weight with Pay load (kg)  226.7 kg
Fuel Tank Capacity  9 L
